Standard End Fastener, M8

Standard End Fastener, M8

Part no. 30-3891

The standard end fastener assembly is comprised of a button head socket cap screw and wing clip. The end fastener provides a fixed, 90 degree, moderate-strength connection that is completely hidden. The winged tabs of the clip prevent the mating profile from rotating. This connection method requires two machining services; an end tap on the mounting profile and an access hole in the mating profile in order to reach the screw head. Additional Information: Wing clips are available separately (without the button head socket cap screw) for instances where you want to create your own custom assembly.

SKU: 30-3891 Categories: , ,
Series30 Series
TypeAssembly
MaterialSteel
ColorBright
A15.00mm
B7.49mm
C8.00mm
D8.50mm
E28.70mm
F21.00mm
GM8
H20.00mm
Weight0.0370
