Part No: 30-3003
30mm X 30mm T-Slotted Profile – Three Adjacent Open T-Slots
30-3003 is a 30mm x 30mm metric 30 series square T-slot profile with three adjacent open T-slots, one on three 30mm faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 30-3003 profile is compatible with 30 series fasteners. The three closed faces on this profile provide a clean, aesthetic look while also having the capability to mount additional profiles, parts and accessories. It lends itself to furniture, displays, desks, trade show booths, or retail kiosks.
Additional information
| Series | 30 Series |
| Material | Aluminum |
| Grade | 6105-T5 |
| Finish | Anodize |
| Color | Clear |
| Drop Lock | 2° |
| Moment of Inertia – IX | 2.6832 cm⁴ |
| Moment of Inertia – IY | 2.6343 cm⁴ |
| Surface Area | 3.065 Sq cm |
| Yield Strength | 241.1 N / Sq mm |
| Modulus of Elasticity | 70,326.5 N / Sq mm |
| Weight lbs | 0.0460 per inch |
| Weight | 0.0460 |
30-3003 is a 30mm x 30mm metric 30 series square T-slot profile with three adjacent open T-slots, one on three 30mm faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 30-3003 profile is compatible with 30 series fasteners. The three closed faces on this profile provide a clean, aesthetic look while also having the capability to mount additional profiles, parts and accessories. It lends itself to furniture, displays, desks, trade show booths, or retail kiosks.
