Part No: 25-2504
25mm X 25mm T-Slotted Profile – Two Opposite Open T-Slots
25-2504 is a 25mm x 25mm metric 25 series square T-slot profile with two opposite open T-slots, one on two 25mm faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 25-2504 profile is compatible with 25 series fasteners. The placement of the T-slots allows support structures or panels to be easily placed into them while maintaining a continuous surface, lending itself to projects such as guarding, furniture or displays.
Additional information
| Series | 25 Series |
| Material | Aluminum |
| Grade | 6105-T5 |
| Finish | Anodize |
| Color | Clear |
| Drop Lock | 2° |
| Moment of Inertia – IX | 2.2730 cm⁴ |
| Moment of Inertia – IY | 1.7761 cm⁴ |
| Surface Area | 3.039 Sq cm |
| Yield Strength | 241.1 N/ Sq. mm |
| Modulus of Elasticity | 70,326.5 N/Sq. mm |
| Weight lbs | 0.0459 per inch |
| Weight | 0.0459 |
25-2504 is a 25mm x 25mm metric 25 series square T-slot profile with two opposite open T-slots, one on two 25mm faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 25-2504 profile is compatible with 25 series fasteners. The placement of the T-slots allows support structures or panels to be easily placed into them while maintaining a continuous surface, lending itself to projects such as guarding, furniture or displays.
