25mm X 25mm T-Slotted Profile – Two Adjacent Open T-Slots

25mm X 25mm T-Slotted Profile – Two Adjacent Open T-Slots

Part no. 25-2502

25-2502 is a 25mm x 25mm metric 25 series square T-slot profile with two adjacent open T-slots, one on two 25mm faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 25-2502 profile is compatible with 25 series fasteners. The two closed faces on this profile provide a clean, aesthetic look while also having the capability to mount additional profiles, parts and accessories. It lends itself to furniture, displays, desks, trade show booths, or retail kiosks.

Unit

SKU: 25-2502 Categories: ,
Series25 Series
MaterialAluminum
Grade6105-T5
FinishAnodize
ColorClear
Drop Lock
Moment of Inertia – IX1.9780 cm⁴
Moment of Inertia – IY1.9780 cm⁴
Surface Area3.039 Sq cm
Yield Strength241.1 N/ Sq. mm
Modulus of Elasticity70,326.5 N/Sq. mm
Weight lbs0.0459 per inch
Weight0.0459



25-2502_dimensional
