Part No: 25-2525
25mm X 25mm T-Slotted Profile – Four Open T-Slots
25-2525 is a 25mm x 25mm metric 25 series square T-slot profile with four open T-slots, one on each 25mm face. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 25-2525 profile is compatible with all 25 series fasteners. This profile lends itself to clean room applications, guards, enclosures, or workstations.
Additional information
| Series | 25 Series |
| Material | Aluminum |
| Grade | 6105-T5 |
| Finish | Anodize |
| Color | Clear |
| Drop Lock | 2° |
| Moment of Inertia – IX | 1.7726 cm⁴ |
| Moment of Inertia – IY | 1.7726 cm⁴ |
| Surface Area | 2.746 Sq cm |
| Yield Strength | 241.1 N/ Sq. mm |
| Modulus of Elasticity | 70,326.5 N/Sq. mm |
| Weight lbs | 0.0415 per inch |
| Weight | 0.0415 |
25-2525 is a 25mm x 25mm metric 25 series square T-slot profile with four open T-slots, one on each 25mm face. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 25-2525 profile is compatible with all 25 series fasteners. This profile lends itself to clean room applications, guards, enclosures, or workstations.
